| Weight (without payload) | 42.5 kg (without battery)
65 kg (with two DB2000 batteries) | 55.2 kg (with lifting system)
60.2 kg (with wind system)
Excluding the weight of the battery, double battery compartment, accessories, cable, and hook. |
| Max. Weight when lifting off | 95 kg (with freight at sea level） | 170 kg
The maximum takeoff weight of 170 kg is the drone's performance specification. Please observe local laws and regulations when actually using the drone. In the following countries and regions, the maximum takeoff weight is limited to 150 kg: Brazil, Japan, Australia, Turkey, Saudi Arabia. |
| Max. diagonal axis distance / Maximum diagonal wheelbase (engine to engine) | 2200 mm | 2330 mm |
| Diagonal length (tip to tip) | | 3904 mm |
| Dimensions | Wing extended, propeller retracted:
1590 × 1900 × 947 mm (L × W × H)
Arm extension and propeller extended:
2800 × 3085 × 947 mm (L × W × H)
Arm extension and propeller retracted:
1115 × 760 × 1027 mm (L × W × H) | Arms and propeller unfolded:
3220 mm × 3224 mm × 975 mm
Arms folded, propeller unfolded:
1820 mm × 1840 mm × 975 mm
Arms and propeller unfolded:
1105 mm × 1265 mm × 975 mm |
| Folding method | Towards the torso | Towards the body |
| Number of rechargeable batteries | 2 | Supports configurations with two batteries and one battery
Single battery mode is intended for emergency use. |
| Hover time (empty weight, with max. battery capacity) | 29 min. (operation with two rechargeable batteries)
15 min. (operation with one battery)
The data was collected under controlled conditions: Zero altitude and no wind. For reference only. | |
| Hover time (max. weight, with max. battery capacity) | 18 min. (30 kg weight, operation with two batteries)
8 min. (40 kg weight, operation with one battery)
The data was collected under controlled conditions: Zero altitude and no wind. For reference only. | "With a takeoff weight of less than 149.9 kg: two batteries 12 km, one battery 6 km
This data was obtained using a DJI FC100 with a fully charged new battery at a takeoff weight of 149.9 kg, flying at a constant optimal speed until the battery was 0% charged in a windless environment at 25°C at sea level. Results may vary depending on the environment, actual usage, and firmware version. Always follow the instructions in the app during operation. |
| Maximum flight distance (empty weight, with maximum battery capacity) | 28 km (operation with two batteries)
12 km (operation with one battery)
The data was collected under controlled conditions: Zero altitude and no wind, at a constant speed of 15 m/s. For reference only. | |
| Maximum flight distance (max. weight, with max. battery capacity) | 16 km (30 kg weight, operation with two batteries)
8 km (40 kg weight, operation with one battery)
The data was collected under controlled conditions: Zero altitude and no wind, at a constant speed of 15 m/s. For reference only. | With a takeoff weight of less than 149.9 kg: two batteries 12 minutes, one battery 6 minutes
This data comes from a DJI FC100 with a fully charged new battery at a takeoff weight of 149.9 kg, hovering in a windless environment at 25°C at sea level until the battery was 0% charged. Results may vary depending on the environment, actual usage, and firmware version. Always follow the instructions in the app during operation. |
| Max. Flight time (max. weight, with max. battery capacity) | 18 min. (30 kg weight, operation with two batteries)
9 min. (40 kg weight, operation with one battery)
The data was collected under controlled conditions: Zero altitude and no wind, at a constant speed of 15 m/s. For reference only. | With a takeoff weight of less than 149.9 kg: two batteries 14 minutes, one battery 7 minutes.
This data was obtained using a DJI FC100 with a fully charged new battery at a takeoff weight of 149.9 kg, flying in a windless environment at 25°C at sea level at a constant optimal speed until the battery was 0% charged. Results may vary depending on the environment, actual usage, and firmware version. Always follow the instructions in the app during operation. |
| Operating temperature | -20 °C to +45 °C | -20 °C to 40 °C
Measured at an estimated solar radiation of 960 W/m². Long-term exposure to high temperatures can shorten the service life of certain components. |
| Protection class | IP55 | IP55
The protection rating is not permanent and may decrease due to aging and wear from long-term use. The protection rating does not apply to the drive system. After flying in the rain, it is recommended to let the device run idle on the ground for 1 minute to prevent corrosion or rust on the drive system (precipitation of more than 0.98 inches within 24 hours).
|
| Hovering accuracy (with strong GNSS signal) | RTK positioning activated:
±10 cm horizontal, ±10 cm vertical
RTK positioning deactivated:
±60 cm horizontal and ±30 cm vertical (radar activated: ±10 cm) | RTK positioning enabled:
± 10 cm (horizontal), ± 10 cm (vertical)
RTK positioning disabled:
± 60 cm (horizontal), ± 30 cm (vertical) |
| RTK/GNSS operating frequency | RTK: GPS L1/L2, Galileo F1/F2, BeiDou B1I/B2I/B3I, Galileo E1/E5b, QZSS L1/L2
GNSS: GPS L1, BeiDou B1I, Galileo F1, Galileo E1, QZSS L1 | GPS + Galileo + BeiDou + GLONASS |
| Max. Pitch angle | 30° | |
| Max. Climbing speed | 5 m/s (The data was recorded under controlled conditions: Zero altitude and no wind, with a payload of 30 kg. For reference only). | 5 m/s
Measured in dual battery mode at sea level at 25 °C and in calm test conditions. |
| Max. Sink rate | 3 m/s (vertical)
5 m/s (inclined)
The data was recorded under controlled conditions: Zero altitude and no wind, with a payload of 30 kg. For reference only. | 5 m/s
Measured in dual battery mode at sea level at 25 °C and in calm test conditions. |
| Maximum speed / Maximum horizontal speed | 20 m/s (The data was recorded under controlled conditions: Zero altitude and no wind, with a payload of 30 kg, for reference purposes only). | 20 m/s
Measured in dual battery mode at sea level at 25 °C and in calm test conditions.
|
| Max. Flight altitude | 6,000 m (without payload) | 6,000 m
The payload capacity of the drone decreases with increasing takeoff altitude. 6,000 m above sea level is the maximum safe altitude for the drone with two batteries and no payload (takeoff at 4,500 m above sea level). |
| Maximum altitude (relative to the starting point) | | 1,500 m
The flight altitude is limited by the takeoff altitude. The maximum flight altitude for DJI FC100 is 6,000 m. |
| Wind resistance | 12 m/s (The data was recorded under controlled conditions: Zero altitude and no wind, with a payload of 30 kg. For reference only). | 12 m/s
The maximum wind speed during takeoff and landing is 12 m/s. |
