Intended use
The AES Power Box is a mobile power station. In trades and on construction sites, it powers devices with up to 3.6 kW of power completely independently of cable reels or generators. The system offers a silent alternative to generator-based power supply. With its practical rolling base, the box can be easily secured in a vehicle or moved to the work site to power cooktops, coolers, and laptops.
The power box is also ideal for providing emergency power at home. Thanks to its use of long-lasting LiFePO4 technology, the power box is designed to withstand daily heavy-duty use and offers a long service life.
Scope of delivery
- Power strip
1 half-pallet, approx. 40 kg
Technical Details
General:
-
Dimensions: 510.5 x 349 x 318 mm.
-
Weight: Net weight: 14 kg. Fully equipped: 41 kg (including two SuperPacks weighing 12 kg each and a Mobility Board).
-
Mobility: An inclusive roll board with four professional-grade casters that rotate 360° and a locking brake. The casters are removable; the board can also be permanently mounted in a vehicle as a non-slip mount.
Performance and capacity:
-
Battery Technology: High-Quality LiFePO4 Cells
-
Capacity: 60 Ah (equipped with 2x 30 Ah AES SuperPacks).
-
Energy capacity: 1,440 Wh (with one SuperPack) 2,880 Wh (with two SuperPacks)
-
Output power (AC): Single operation: 2.3 kW, Parallel operation (two power boxes): 3.6 kW
-
Service life: Over 3,000 charge cycles (at 80% remaining capacity).
Connections and charging:
-
Inputs: AC charging: Up to 1600 W (with two SuperPacks) / 230 V mains connection; Solar input: 12–60 V, max. 25 A.
-
DC outputs: USB-C: up to 30 W, USB-A: up to 15 W, wireless charging: 15 W
-
Management: Integrated smart BMS with CAN bus communication for optimal control and monitoring.
Information on product safety
Manufacturer:
AES Akku Energie Systeme GmbH
Warwischer Hinterdeich 170
21037 Hamburg
Facts
Product Features
-
Maximum independence
Thanks to the rollboard with 360° smooth-rolling professional casters, the power box can be maneuvered effortlessly, even when both SuperPacks are installed. The system is designed so that the board not only serves as a means of transport but can also be permanently mounted in the vehicle.
-
Durable & powerful
Equipped with a high-quality LiFePO battery and capable of over 3,000 charge cycles, the AES power box guarantees an exceptionally long service life. An intelligent battery management system (Smart BMS) with CAN bus communication protects against overloading and ensures maximum operational reliability in daily use.
-
Quiet & efficient
Since the system operates without an internal combustion engine, it can be used indoors, in vehicles, or in noise-sensitive areas without disrupting workflows or the surrounding environment. The system minimizes standby losses and, thanks to the Smart BMS, ensures that stored energy is delivered precisely where it is needed.
